Rapido V KF/KZ

Applied perfection

Italkart logo

Rollover parts to highlight >>

Tube Size: 30 mm
Axle Size: 50mm Standard
Axle Bearings: 3
Brake System: EV010 Hydraulic
Master Cylinders: Reservoir self adjusting
Rear Rotor: Floating Vented
Front Rotors: Fixed Vented
Fuel Tank: 8.5 litres
Spindles: 10.5 or 11 Degree
Torsion Bars: Front - Side - Rear
Front Ride Height: Adjustable
Rear Ride Height:
Wheelbase:
Adjustable
Fixed
Rapido V Frame
Additional Rapido V Information >>
© 2026 ITALKART · All rights reserved | Contact | Home |

Special 30mm chromolly tubing

Standard 50mm Axle

Adjustable wheelbase and ride height

Brake Line securely mounted to chassis

Reservoir based master cylinder makes for consistent braking and eliminates the need for shims


4 piston rear Caliper with Floating rotor

Billet front calipers with benjo fittings

8.5 Liter anti Splash fuel tank

4 Bearing Billet front Spindles provide extra strength and precise castor angles

Removeable torsion bar

Adjustable Camber/Castor pills are standard with the optional lower adjustable pills available

Adjustable exhaust mount
